IP Products
We offer two types of IP CoreProducts: All-in-one solutions that can be tailored to your needs, or individual IP cores that can be combined according to your requirements.
All IP cores are available as source code licenses.
Complete Synchronization Solution: Universal Time Sync (UTS)
NetTimeLogic provides a complete synchronization solution that allows to interconnect all kind of synchronization IP cores. It allows to bridge between PTP, IRIG, PPS, RTC, NTP or TOD protocols. Each protocol can be configured to be in master or slave mode. All cores share a common clock that can be synchronized by any of those cores and can be the source of time for all other cores. In addition to synchronization, the NetTimeLogic solution provides configurable signal or frequency generators and timestampers to interact with user logic aligned with the synchronized clock.
Synchronization Products
The complete synchronization solution is split up into individual cores which can all be purchased individually and combined as needed.
PTP Products
NetTimeLogic provides four kinds of PTP cores based on IEEE1588: PTP Ordinary Clock, PTP Grandmaster Clock, PTP Transparent Clock and PTP Hybrid Clock
NTP Products
NetTimeLogic provides a high performance NTP Server for synchronizing 100k+ Clients from a single Server as well as a simple SNTP Client for easy integration
PPS Products
NetTimeLogic provides three kinds of PPS cores: PPS Master, PPS Slave and a PPS Clock to PPS generator
IRIG Products
NetTimeLogic provides two kinds of IRIG cores: IRIG Master and IRIG Slave
TOD Products
NetTimeLogic provides two kinds of TOD (Time of Day) cores based on NMEA 0183, UBX and TSIP: TOD Master and TODSlave
DCF Products
NetTimeLogic provides two kinds of DCF cores: DCF Master for DCF over a wire andDCF Slave for synchronizing to a DCF77 source
RTC Products
NetTimeLogic provides a RTC Master for synchronizing to an external battery backed RTC
Clock Products
NetTimeLogic provides individual clock related products: Adjustable Clock, Signal Generator, Frequency Generator and Signal Timestamper
SyncE Products
NetTimeLogic provides a SyncE Node for ESMC handling, clock muxing and synchronization
Complete Network Redundany Solution: Universal Net Red (UNR)
NetTimeLogic provides a complete network redundancy solution that allows to combine the network redundancy IP core with the time synchronization IP cores. It allows to create a high availability network with time synchronization support according to PTP. In addition to synchronization, the NetTimeLogic solution provides configurable signal or frequencygenerators and timestampers to interact with user logic aligned with the synchronized clock.
Network Redundancy Products
The complete network redundancy solution is split up into individual cores which can all be purchased individually and combined as needed.
Redundancy Products
NetTimeLogic provides network redundancy solutions based on IEC62439: HSR and PRP
Time Sensitive Networking Solution (TSN)
The time sensitive networking (TSN) solutions are split up into individual cores which can all be purchased individually and combined as needed.
TSN Products
NetTimeLogic provides complete Time Sensitive Network (TSN) solutions which are composed out of multiple cores from NetTimeLogic. In addition we provide a companion core for taking part atthe IIC(R) Testbed.
